Flip-up flood barrier for garages

Short Description:

Warning! This equipment is an important flood control safety facility. The user unit shall designate professional personnel with certain mechanical and welding knowledge to conduct regular inspection and maintenance, and shall fill in the inspection and maintenance record form (see the attached table of the product manual) to ensure that the equipment is in good condition and normal use at all times! Only when the inspection and maintenance are carried out in strict accordance with the following requirements and the “inspection and maintenance record form” is filled in, can the company’s warranty terms take effect.

Our advantages:

1. **Fully Automated Without Electrical Dependency**: Operates normally during power outages in extreme weather.

2. **Unmanned Operation**: Automatically rises to block water when the water level reaches the trigger point, providing 24/7 flood control with automatic adjustment of the gate’s opening angle according to water level changes.

3. **Ground-Flat Storage**: Lays flat on the ground, occupying no space and allowing unimpeded pedestrian and vehicle traffic.

4. **Emergency Vehicle Passage**: In the early stage of water blocking, garage vehicles can drive over the water-blocking panels for evacuation.

5. **Modular Design**: Enables quick installation without major modifications.

6. **Anti-Collision Warning Lights**: Prevents accidental impacts by pedestrians and vehicles during flood control.

7. **Optional Remote Networking Supervision System**: Enables intelligent flood control management.

8. **Minimal Maintenance**: Only requires periodic cleaning of debris at the gate’s base.

9. **Dual-Mode (Manual & Automatic) Operation**: Enhances flood control flexibility.

10. **Durable Materials**: Ensures a service life of up to 10 years.


Product Detail

FAQ

Product Tags

Model water retaining height installation mode installation groove section bearing capacity
Hm4e-0012C  1150 embedded installation width1540 * depth: 105  heavy duty (small and medium-sized motor vehicles, pedestrian)



Grade Mark Bearing capacity (KN) Applicable occasions
Heavy duty C 125 underground parking lot, car parking lot, residential quarter, back street lane and other areas where only allow non-fast driving zone for small and medium-sized motor vehicles (≤ 20km / h).

Regular maintenance and inspection for the automatic flood barrier

Warning! This equipment is an important flood control safety facility. The user unit shall designate professional personnel with certain mechanical and welding knowledge to conduct regular inspection and maintenance, and shall fill in the inspection and maintenance record form (see the attached table of the product manual) to ensure that the equipment is in good condition and normal use at all times! Only when the inspection and maintenance are carried out in strict accordance with the following requirements and the “inspection and maintenance record form” is filled in, can the company’s warranty terms take effect.

1 ) [important] every month and before each heavy rain, manually pull and place the door leaf at least once, and clean up the sundries in the bottom frame! In order to prevent the door leaf from being stuck by foreign matters and unable to be opened normally; at the same time, the sediment, leaves and other sundries inside the bottom frame and water inlet shall be cleaned up to prevent the water inlet channel (GAP) from being blocked after the door leaf is closed, which hinders the flow of water and can not produce buoyancy, resulting in the door leaf not being able to automatically open and block the water; the deposited sediment, leaves and other sundries will accelerate the corrosion and shorten the service life of the equipment. When the door leaf is opened, the warning light shall flash at high frequency.

1) [important] conduct water injection test at least once a year before flood season! At the front of the flood control barrier, sandbags or manual plates are used to make the dam enclosure, and the drainage switch at the rear under the bottom frame is closed with tools such as screwdrivers. Water is poured in between the dam enclosure and the flood control barrier. The door leaf shall be able to automatically do the water retaining, and there is no obvious water leakage as a whole, and the warning light shall flash at high frequency. In case of surface installation on the slope, the drain switch shall be turned on after the test.

1 (1)

5
